Bay 1 and Bay 2 Interfaces (M6220 and M8024)
The PowerConnect M6220 supports dual 10G slot interfaces. These interfaces can operate at 10 Gbps
when supporting optional 10GE modules, or 12 Gbps (top slot only) when supporting a stacking module.
Figure 3-2 illustrates the 10G slots.
The Dell™ PowerConnect™ M8024 supports dual 10 Gb slot interfaces. These interfaces can operate at
10 Gbps when supporting optional SFP+ or CX4 modules. Figure 3-3 illustrates the 10 Gb slots.
Figure 3-2. Bay 1 and Bay 2 PowerConnect M6220 Series 10 Gb Slots
Figure 3-3. Bay 1 and Bay 2 PowerConnect M8024 10 Gb Slots
