50 Hardware Description
PowerConnect Front Panel
PowerConnect M6348 Front Panel
The PowerConnect M6348 front panel provides 16 10/100/1G Base-T ports. There are also 32 internal
1 gigabit ports that connect to each of the server blades.
Figure 4-1. PowerConnect M6348
10 Gb CX4 Ports
Console Port
10/100/1000Base-T Auto-sensing
Full Duplex RJ-45 Ports
10 Gb SFP+ Ports
