Chapter 3 Connect the Back End
92 Storage Center SC8000 Controller Deployment Guide
Chain2:ASide 1 ControllerA:slot6,port3→Enclosure5:topSBB,portC.
2StartingwithEnclosure5,daisy‐chaintheAsideofChain2bycabling:top
SBB,portB→nextenclosuredown:topSBB,portA.
3 FinishwithEnclosure8:topSBB,portC
?ControllerB:slot 6,port1.
Chain2:BSide 1 ControllerA:slot5,port1→Enclosure8:bottomSBB,portC.
2StartingwithEnclosure8,daisy‐chaintheBsideofChain2bycabling:bottom
SBB,portB→nextenclosureup:bottomSBB,portA.
3 FinishwithEnclosure5:bottomSBB,portC→ControllerB:slot 5,port3.
Path Connections
