Dell SC8000 - Single Controller, Single Enclosure, Low Profile SAS

Connect SC200/SC220 Enclosures
Dell Compellent 61
Single Controller, Single Enclosure, Low Profile SAS
Thisillustration showsanSC8000controllercabledtoa6GbSASenclosureusingalow
profileSASIOcardinalowprofilecardslot.
Figure 60. Single SC8000 Controller, Single SAS Enclosure, Low Profile SAS IO Card
Path High-Level Steps
Chain1:SideA 1 Connectthefirstcontrollerport1tothefirstenclosure,topEMM,portA.
2 ConnecttheremainingenclosuresinseriesfromBporttoAportusingthetop
EMMs.
3IftheStorageCenterhasdual‐controllers,connectthelastenclosure,topEMM,
portBtothesecondcontroller,port3.
Chain1:SideB 1 Connectthefirstcontrollerport3tothelastenclosure,bottomEMM,portB.
2 ConnecttheremainingenclosuresinseriesfromAporttoBportusingthe
bottomEMM.
3IftheStorageCenterhasdual‐controllers,connectthetopenclosure,bottom
EMM,portAtothe
secondcontroller,port1.
Note: The cablingillustrationsinthischapterrefertoenclosuresasEnclosure1,
Enclosure2,andsoon.Thenumbersshownintheillustrationsmaynotmatchthe 
IndexnumberassignedbytheSystemManager.StorageCenterassignsanIndex
onlyafterthesystemispoweredupandatleastone
driveisassignedtoaDisk
Folder.
Path Connections
Chain1:ASide Controller:slot3,port1→Enclosure:topEMM,port A.
Chain1:BSide Controller:slot3,port3→Enclosure:bottomEMM,port B.
4321
A
AB
B
