Connect the Front End for a Dual-Controller Storage Center
Dell Compellent 111
See Also
RequirementsforVirtualPortModeonpage 97
FibreChannelZoningonpage 10 2
Connect iSCSI Servers
ChoosetheiSCSIconnectivityoptionthatbestsuitsthefront‐endredundancy
requirementsandnetworkinfrastructure.
 LegacyModewithSingle‐NetworkiSCSIonpage 111
 LegacyModewithDual‐NetworkiSCSIonpage 112
 VirtualPortModewithSingle‐NetworkiSCSIonpage 114
 VirtualPortModewithDual‐NetworkiSCSIonpage 115
Legacy Mode with Single-Network iSCSI
ConnectlegacymodeiSCSItoasinglenetworkifonlyoneEthernetswitchisavailableand
youwanttoprotectagainstcontrollerfailure.
Inthisconfiguration,twofaultdomainsarespreadacross bothcontrollers.Eachfault
domaincontainssetsofprimaryandreservepaths(P1‐R1andP2‐R2).Thereserved
paths
provideredundancyforsinglecontrollerfailure.Thisconfigurationisvulnerabletosw itch
failure.
Prerequisites
EachcontrollermusthavetwoavailableiSCSIfront‐endports.
Steps
1 ConnecteachiSCSIservertobothEthernetswitches.
2 Connectfaultdomain1(showninorange)toswitch1.
 PrimaryportP1:ControllerA,slot3,port1→Switch1
 ReservedportR1:ControllerB,slot3,port1→Switch1
3 Connectfaultdomain2(showninblue)toswitch1.
 PrimaryportP2:ControllerB,slot4,port2→Switch1
 ReservedportR2:ControllerA,slot4,port2→Switch1
Note: Topreventaportorcablefailurefromblockingaccesstovolumesmappedto
acontroller,connecttwoadditionalfaultdomainssothateachcontrollerhastwo
primarypathstotheiSCSInetwork.
