EN-SASx6x12/24 Drive Numbering
InEN‐SASX6X12andEN‐SASX6X24enclosures,drivesarenumberedfromlefttoright
startingfrom1.StorageCenteridentifiesdrivesas
Disk-XX‐YY,whereXXisthenumberof
theenclosurethatphysicallycontainsthedrive,andYYisthedrivepositioninsidethe
enclosure.
 EN‐SASX6X12:Drivesarenumberedinrowsstartingfrom1atthetop‐leftdrive.
Figure 30. EN-SASx6x12 Enclosure Drive Numbering
 EN‐SASX6X24:Drivesarenumberedstartingfrom1attheleft‐mostdrive.
Figure 31. EN-SASx6x24 Enclosure Drive Numbering
Drive 1
Drive 5
Drive 9
Drive 2
Drive 6
Drive 10
Drive 3
Drive 7
Drive 11
Drive 4
Drive 8
Drive 12
2413246 10115 7 8 9 12 13 14 16 17 18 19 20 21 22 2315
