Dell SC8000 - Fan Module Features and Indicators

Chapter 1 Introduction
18 Storage Center SC8000 Controller Deployment Guide
Fan Module Features and Indicators
SC280enclosuresincludefivefanmodulesinfiveinterfaceslots.
Figure 14. SC280 Fan Module Features and Indicators
Item Control/Feature Icon Description
1Releaselatch
2ModuleOK Green—ModuleOK
3 Batteryfault Notcurrentlyused
4Fanfault Amber—Lossofcommunicationwiththefanmodule,
orreportedfanspeedisoutoftolerance
1
2
3
4
