Chapter 3 Connect the Back End
76 Storage Center SC8000 Controller Deployment Guide
See Also
SASEnclosureCablingGuidelinesonpage 55
Single Controller, Single SC280 Enclosure
Thisillustration showsanSC8000controllercabledtoasingleSC280enclosure.
Figure 73. Single SC8000 Controller, Single SC280 Enclosure
Path Connections
Chain1:ASide Controller:slot3,port1→Enclosure:leftEMM,port C.
Chain1:BSide Controller:slot3,port3→Enclosure:rightEMM,port C.
AB
1342
CABC
4 3 21
