Dell SC8000 - Single Controller, Two SC280 Enclosures

Connect SC280 Enclosures
Dell Compellent 77
Single Controller, Two SC280 Enclosures
Thisillustration showsasingleSC8000controllercabledtotwoSC280enclosures.
Figure 74. Single SC8000 Controller, Two SC280 Enclosures, Single Chain
Path Connections
Chain1:ASide 1 Controller:slot3,port1→Enclosure1:leftEMM,port C.
2Enclosure1:leftEMM,portB→Enclosure2:leftEMM,port A.
Chain1:BSide 1 Controller:slot3,port3→Enclosure2:rightEMM,portC.
2Enclosure2:rightEMM,portB→Enclosure1:right
EMM,portA.
Enclosure 1
Enclosure 2
Controller
AB
1342
CABC
AB C AB C
4 3 21
