SC280 Back-Panel Features and Indicators
Theenclosurebackpanelprovidescontrolstopowerupandresettheenclosure,indicators
toshowtheenclosurestatus,andconnectionsforback‐endcabling.
Figure 11. SC280 Back Panel Identification
Item Name
1Optionalcableretentionpositions(4).
2IOenclosuremanagementmodules(2).SeeSC280EMMFeaturesandIndicatorson
page 16.
3Fanmodules(5).
4Powersupplyunits(2).SeeSC280PowerSupplyUnitFeaturesandIndicatorsonpage 17.
5Powerswitches(2).
6Optionalcableretentionpositions(2).
2
1
4
3
5
6
