SC280 Enterprise Plus Drives
EnterprisePlusDrivescanonlybeinstalledinSC280enclosures.Anindicatorgiv esstatus
andactivityinfo rmationasdescribedbelow.
Figure 15. SC280 Hard Drive Indicators
Item Name Indicator Code
1 Harddriveactivityindicator • SteadyAmber—Drivefault
• FlashingAmber(on1sec/off1sec)—Driveorenclosure
indicatorissettoOninSystemManager.(Withthedrive
indicator,thecontainingdrawerfaultLEDalsoflashes;
withtheenclosureindicator,alldrives’andbothdrawers’
fault
LEDsflash.)
