Chapter 5 Set up the Storage Center Software
124 Storage Center SC8000 Controller Deployment Guide
Turn on the Hardware
Turnontheenclosuresfirst,andafterthedisksspinup,turnonthecontrollers.
1 Connecttheenclosuresandcontroller(s)toapowersource.
2 TurnoneachenclosureattachedtotheStorageCenter.
a Simultaneouslypressbothpowerswitchesontherearoftheenclosuretoturnonthe
enclosure.
b Repeat
witheachenclosureattachedtotheStorageCenter,waitingforthe disksto
spinupbetweenenclosures.
3 Turnoneachcontrollerbypressingandholdingthepowerbuttononthefrontofthe
controller.Thefansturnonasanindicationthatthecontrollerisstartingtocomeup.
Configure the Controller(s)
Useaserialconnectiontothecontroller(s)tosettheinitialconfiguration.
Reset Hardware and System Serial Numbers
Configurethecontroller(s)withtheHSNandSSNprovidedinthepre‐installation
documents.
1 Establishaserialconnectiontothecontroller.
a UseanRS‐232serialcabletoconnectaPCorlaptoptoaStorageCentercontroller’s
RS‐232serialport.(ToconnectfromaUSBport,useaUSB
toRS‐232converter.)
b TurnonthePC.
c Openaterminalemulatororacommand‐lineinterface.Configuretheconnectionas
showninthefollowingtabl e.
Note: Makesurethatalldisksareupandspinningatfullspeedbeforeturning
onanycontrollers.
Note: Ifconfiguringadual‐controllerStorageCenter,performthistaskforboth
controllers.UsethelowestserialnumberforController1.
Setting Value
Emulation VT220
ColumnMode 132
LineWrapping Off
Connection SerialPort
ConnectionType Direct
BaudRate 115,200
Parity None
DataBits 8
StopBits 1
FlowControl Hardwareordefault
