Appendix A Adding or Removing an Enclosure
182 Storage Center SC8000 Controller Deployment Guide
Figure 115. Disconnect Controllers (B Side)
Disconnect
Controllers,
B-side
Move Cable to
Enclosure 2,
port C
Enclosure 1
Enclosure 2
Controller A
Controller B
ABC
4321
4321
ABC
ABC ABC
