Appendix A Adding or Removing an Enclosure
192 Storage Center SC8000 Controller Deployment Guide
7 ConnectControllerA: port4→newEnclosure3:bottom,portB.
8 ConnectEncl osure3:bottom,portA→ControllerB:port2.
9 IntheStorageCenterSystemManager,selectStorageManagement→System→
Setup→ConfigureLocalPorts.
10 Makesuretha t:
 SlotandslotportsareUpandthePurposeissettoback‐end.
 TargetCountequalsthenumberofaddeddrives,demonstratingthatthecontroller
recognizesthenewenclosures.
Figure 123. Adding an SC200/220 SAS Enclosure, B side
Enclosure 1
Enclosure 2
Controller A
Controller B
Enclosure 2
