Appendix A Adding or Removing an Enclosure
194 Storage Center SC8000 Controller Deployment Guide
Figure 124. Disconnecting the SC280 Enclosure from the A side
Enclosure 1
Enclosure 2
Controller A
Disconnect A side
Remove the A-side
cable between
enclosures
Controller B
ABC
4321
4321
ABC
ABC ABC
