Removing Enclosures
Dell Compellent 201
Figure 129. Reconnecting the SC200/220 A side
Enclosure 1
Enclosure 2
Enclosure 3
Enclosure 4
Controller A
Reconnect A side, after
moving the cable below
Move the A-side cable
to next enclosure
Controller B
