Removing Enclosures
Dell Compellent 203
Figure 130. Disconnecting the SC200/220 Enclosure from the B-side Chain
Disconnect
B side
Remove the B-side
cable between
enclosures
Enclosure 1
Enclosure 2
Enclosure 3
Enclosure 4
Controller A
Controller B
Move to Enclosure
2, bottom, port A
