Chapter 3 Connect the Back End
72 Storage Center SC8000 Controller Deployment Guide
Path Connections
Chain1:ASide 1 Controller A:slot2port1→Enclosure1:topEMM,portA.
2Enclosure1:topEMM,portB→Enclosure2:topEMM,portA.
3Enclosure2:topEMM,portB→ControllerB:slot2,port3.
Chain1:BSide 1 Controller B:slot3port1→Enclosure
1:bottomEMM,portA.
2Enclosure1:bottomEMM,portB→Enclosure2:bottomEMM,portA.
3Enclosure2:bottomEMM,portB→ControllerA:slot3,port3.
Chain2:ASide 1 Controller A:slot2,port 3→Enclosure3:topEMM,portA.
2Enclosure3:topEMM,portB→
Enclosure4:topEMM,portA.
3Enclosure4:topEMM,portB→ControllerB:slot2,port1.
Chain2:BSide 1 Controller B:slot3,port3→Enclosure3:bottomEMM,portA.
2Enclosure3:bottomEMM,portB→Enclosure4:bottomEMM,portA.
3Enclosure4:bottomEMM,port
B→ControllerA:slot3,port1.
