Chapter 3 Connect the Back End
80 Storage Center SC8000 Controller Deployment Guide
Path Connections
IPC 1 ControllerA:slot3,port2→ControllerB:slot3,port4.
2 ControllerB:slot3,port2→ControllerA:slot3,port 4.
Chain1:ASide 1 ControllerA:slot3,port1→Enclosure:1leftEMM,portC.
2Enclosure1:leftEMM,portB→Enclosure:2left
EMM,portA.
3Enclosure2:leftEMM,portC→ControllerB:slot3,port3.
Chain1:BSide 1 ControllerB:slot3,port1→Enclosure:1rightEMM,portC.
2Enclosure1:rightEMM,portA→Enclosure:2rightEMM,portB.
3Enclosure2:rightEMM,portC→
ControllerA:slot3,port3.
