Chapter 11 Summary of Parameter Settings
MH300
11-5
Pr. Parameter Name Setting Range Default
40: Torque command (L.) (unit: %)
41: kWh (J) (unit: kWh)
42: PID target value (h.) (unit: %)
43: PID offset (o.) (unit: %)
44: PID output frequency (b.) (unit: Hz)
46: Auxiliary frequency value (U.) (unit: Hz)
47: Master frequency value (A) (unit: Hz)
48: Frequency value after addition and subtraction of
auxiliary and master frequency (L.) (unit: Hz)
51: PMSVC torque offset
52: Signal of analog extension card input terminal AI10 (4.)
(unit: %)
53: Signal of analog extension card input terminal AI11 (5.)
(unit: %)
55: Display the current reel diameter under the tension
control (d) (unit: mm)
56: Display the current line speed under the tension
control (L) (unit: m / minute)
57: Display the current tension setting value under the
tension control (T) (unit: N)

00-05
Coefficient gain in actual
output frequency
0.00–160.00 1.00
00-06 Firmware version Read only Read only

00-07
Parameter protection
password input
0–65535
0–4 (the number of password attempts)
0

00-08
Parameter protection
password setting
0–65535
0: No password protection / password entered correctly
in Pr.00-07
1: Parameters have been locked
0
00-10 Control mode
0: Speed mode
1: Position control mode
2: Torque mode
0
00-11 Speed control mode
0: IMVF (IM V/F control)
1: IMVFPG (IM V/F control + encoder)
2: IM / PM SVC (IM / PM space vector control)
3: IMFOCPG (IM FOC vector control + encoder)
4: PMFOCPG (PM FOC vector control + encoder)
5: IMFOC sensorless
(IM field-oriented sensorless vector control)
7: IPM sensorless (Interior PM field-oriented sensorless
vector control)
0
