Chapter 11 Summary of Parameter Settings
MH300
11-19
Pr. Parameter Name Setting Range Default
68: SO output logic B
69: Maximum reel diameter reached
70: Empty reel diameter reached
71: Broken belt detection
72: Tension PID feedback error
73: Over-torque 3
74: Over-torque 4

02-18
Multi-function output
direction
0000h–FFFFh (0: N.O.; 1: N.C.) 0000

02-19
Terminal counting value
reached (returns to 0)
0–65500 0

02-20
Preliminary counting value
reached
(does not return to 0)
0–65500 0

02-21 Digital output gain (DFM) 1–55 1

02-22
Desired frequency reached
1
0.00–599.00 Hz
60.00 /
50.00

02-23
The width of the desired
frequency reached 1
0.00–599.00 Hz 2.00

02-24
Desired frequency reached
2
0.00–599.00 Hz
60.00 /
50.00

02-25
The width of the desired
frequency reached 2
0.00–599.00 Hz 2.00

02-34
Output frequency setting
for multi-function output
terminal
0.00–599.00 Hz 0.00

02-35
External operation control
selection after reset and
reboot
0: Disable
1: Drive runs if the RUN command remains after reset or
reboot.
0

02-47 Motor zero-speed level 0–65535 rpm 0

02-48
Maximum frequency of
resolution switch
0.01–599.00 Hz (use with MI setting as 43)
60.00

02-49
Switch delay time of
maximum output frequency
0.000–65.000 sec. 0.000
02-50
Display the status of
multi-function input
terminal
Monitor the status of multi-function input terminals Read only
02-51
Display the status of
multi-function output
terminal
Monitor the status of multi-function output terminals Read only
