Chapter 11 Summary of Parameter Settings
MH300
11-57
Pr. Parameter Name Setting Range Default

12-39
Reel diameter calculation
delay time
0.0–6553.5 sec. 0.0

12-40 Current reel diameter 1.0–6000.0 mm 1.0

12-41
Minimum output frequency
for reel diameter
calculation
0.00–599.00 Hz 1.00
12-42
Pre-startup mode
selection
0: Disabled
1: Pre-startup of rewind mode
2: Pre-startup of unwind mode
0
12-43
Switching level for pre-
startup and PID enable
0.0–100.0% (according to Pr.12-05) 15.0
12-44 Pre-startup frequency 0.00–599.00 Hz 2.00

12-45
Pre-startup acceleration
time
0.01–600.00 sec. 3.00
12-46
Broken belt detection
function
0: Disabled
1: Enabled
0
12-47
Minimum linear speed of
broken belt detection
0.0–3000.0 m/min. 0.0
12-48
Reel diameter error of
broken belt detection
1.0–6000.0 mm 100.0
12-49 Broken belt detection time 0.00–100.00 sec. 1.00
12-50
Tension PID feedback
error level
0–100% 100
12-51
Tension PID feedback
error detection time
0.0–10.0 sec. 0.5
12-52
Tension PID feedback
error treatment
0: Warn and continue operation
1: Fault and ramp to stop
2: Fault and coast to stop
0
12-54
Tension command source
selection
0: RS-485 communication input
1: Analog input
0
12-55 Maximum tension value 0–65535 N 0

12-56
Tension command setting
value
0–65535 N 0
12-57
Zero-speed tension
setting source
0: Disabled
1: RS-485 communication input
2: Analog input
0

12-58
Zero-speed tension
setting value
0–65535 N 0

12-59
Zero-speed tension
threshold (line speed)
0–100.00% 0
