Delta MH300 Series - Page 322

Chapter 11 Summary of Parameter Settings
MH300
11-63
Pr. Parameter Name
Setting Range
Default

14-26
AI10 extension card
mid-point
Pr.14-18 = 0: 0.00–10.00 V
Pr.14-18 ≠ 0: 0.00–20.00 mA or 4–20 mA
5.00

14-27
AI10 extension card
proportional mid-point
0.00–100.00% 50.00

14-28
AI10 extension card
highest point
Pr.14-18 = 0: 0.00–10.00 V
Pr.14-18 ≠ 0: 0.00–20.00 mA or 4–20 mA
10.00

14-29
AI10 extension card
proportional highest point
0.00–100.00% 100.00

14-30
AI11 extension card lowest
point
Pr.14-19 = 0: 0.00–10.00 V
Pr.14-19 ≠ 0: 0.00–20.00 mA or 4–20 mA
0.00

14-31
AI11 extension card
proportional lowest point
0.00–100.00% 0.00

14-32
AI11 extension card
mid-point
Pr.14-19 = 0: 0.00–10.00 V
Pr.14-19 ≠ 0: 0.00–20.00 mA or 4–20 mA
5.00

14-33
AI11 extension card
proportional mid-point
0.00–100.00% 50.00

14-34
AI11 extension card
highest point
Pr.14-19 = 0: 0.00–10.00 V
Pr.14-19 ≠ 0: 0.00–20.00 mA or 4–20 mA
10.00

14-35
AI11 extension card
proportional highest point
0.00–100.00% 100.00

14-36
AO10 terminal analog
signal mode
0: AVO10 (analog voltage signal 0.00–10.00 V)
1: ACO10 (analog current signal 0.0–20.0 mA)
2: ACO10 (analog current signal 4.0–20.0 mA)
0

14-37
AO11 terminal analog
signal mode
0: AVO11 (analog voltage signal 0.00–10.00 V)
1: ACO11 (analog current signal 0.0–20.0 mA)
2: ACO11 (analog current signal 4.0–20.0 mA)
0
14-50
Output frequency at
malfunction 2
0.00–599.00 Hz Read only
14-51
DC voltage at malfunction
2
0.0–6553.5 V Read only
14-52
Output current at
malfunction 2
0.00–655.35 Amps Read only
14-53
IGBT temperature at
malfunction 2
-3276.7–3276.7ºC Read only
14-54
Output frequency at
malfunction 3
0.00–599.00 Hz Read only
14-55
DC voltage at malfunction
3
0.0–6553.5 V Read only
14-56
Output current at
malfunction 3
0.00–655.35 Amps Read only
