Chapter 12 Descriptions of Parameter Settings
MH300
18: Display the current multi-step speed (S)
19: Display corresponding CPU digital input pin status (d)
20: Display corresponding CPU digital output pin status (0.)
21: Actual motor position (PG1 of PG card) (P.)
(The maximum value is 32 bits to display)
22: Pulse input frequency (S.)
23: Pulse input position (q.)
24: Position command tracing error (E.)
25: Overload count (0.00–100.00%) (o.) (unit: %)
26: Ground fault GFF (G.) (unit: %)
27: DC bus voltage ripple (r.) (unit: V
DC
)
28: Display PLC register D1043 data (C)
29: Display permanent magnet synchronous motor pole section
(for EMM-PG01R)
30: Display the output of user-defined parameter (U)
31: Display Pr.00-05 user gain (K)
32: Number of actual motor revolutions during operation (PG card plugs in
and Z phase signal input) (Z.)
33: Actual motor position during operation (when PG card is connected) (q)
35: Control mode (t.): 0 = Speed control mode (SPD)
1 = Torque control mode (TQR)
36: The current operating carrier frequency of the drive (J.) (unit: Hz)
38: Display the drive status (6.)
39: Display the drive’s estimated output torque, positive and negative, using
N-m as unit (0.0: positive torque; -0.0: negative torque) (C.)
40: Torque command (L.) (unit: %)
41: kWh (J) (unit: kWh)
42: PID target value (h.) (unit: %)
43: PID offset (o.) (unit: %)
44: PID output frequency (b.) (unit: Hz)
46: Auxiliary frequency value (U.) (unit: Hz)
47: Master frequency value (A ) (unit: Hz)
48: Frequency value after addition and subtraction of master and auxiliary
frequency (L.) (unit: Hz)
51: PMSVC torque offset
52: Signal of analog extension card input terminal AI10 (4.) (unit: %)
53: Signal of analog extension card input terminal AI11 (5.) (unit: %)
55: Display the current reel diameter under the tension control (d) (unit: mm)
56: Display the current line speed under the tension control (L) (unit: m / min.)
57: Display the current tension setting value under the tension control (T)
(unit: N)
