Chapter 12 Description of Parameter Settings
MH300
Settings
Functions Descriptions
31 High torque bias
Refer to Pr.11-30–11-32 for details.
32 Middle torque bias
33 Low torque bias
35
Enable single-point
positioning
ON: the AC motor drive executes internal single-point position
control according to the setting for Pr.10-19. This function is
valid in FOCPG mode only.
37
Enable pulse-train
position command
position control
When Pr.00-20 is set to 4 or 5, ON: the input pulse of the PG card
is the position command. When using this function, set Pr.11-25
to 0.
Example: refer to the following diagram when using this function
with MI=d35 returning to homing position.
38
Disable to write
EEPROM function
ON: writing to EEPROM is disabled. Changed parameters are
not saved after power off.
