Delta MH300 Series

Chapter 12 Description of Parameter Settings
MH300
12.1-12-12
Position
Pulse
signal
Signal
interface
Parameter
settings
Related parameters Note
Motor
axle
Encoder
PG1 Pr.10-00 = 1
Pr.12-27 = 3
Pr.12-02, Pr.12-03, Pr.12-35,
Pr.12-36
The settings of Pr.10-01 and
Pr.10-02 are depending on
the working condition
PG2
Pr.10-00 = 1
Pr.10-16 = 1, 2
Pr.12-27 = 3
Pr.12-02, 12-03, 12-34, 12-35,
12-36
N/A
MI6 / MI7
Pr.10-00 = 5
Pr.10-16 = 1, 2
Pr.12-27 = 5
Pr.12-02, Pr.12-03, Pr.12-34,
Pr.12-35, Pr.12-36
Uses two-phase input by
MI6 / MI7, and considers the
direction
Advanced
switch
MI7
Pr.10-00 = 5
Pr.10-16 = 5
Pr.12-27 = 5
Pr.12-02, Pr.12-03, Pr.12-34,
Pr.12-35, Pr.12-36
N/A
Rewind
axle
Encoder
PG2 Pr.10-00 = 1
Pr.12-27 = 2
Pr.12-34, Pr.12-35, Pr.12-36
The setting of Pr.10-16 is
depending on the working
condition
MI6 / MI7
Pr.10-00 = 5
Pr.10-16 = 1, 2
Pr.12-27 = 4
Pr.12-34, Pr.12-35, Pr.12-36
Uses two-phase input by
MI6 / MI7, and considers the
direction
Advanced
switch
MI7
Pr.10-00 = 5
Pr.10-16 = 5
Pr.12-27 = 4
Pr.12-34, Pr.12-35, Pr.12-36
N/A
12-28
Maximum Reel Diameter
Default: 6000.0
Settings 1.0–6000.0 mm
12-29
Empty Reel Diameter
Default: 1.0
Settings 1.0–6000.0 mm
12-30
Initial Reel Diameter Source
Default: 1
Settings 0: RS-485 communication input (Pr.12-31)
1: Analog input (Pr.03-00–03-01 = d16)
 When setting as 1, 10 V corresponds to the maximum reel diameter (Pr.12-28).

12-31
Initial Reel Diameter
Default: 1.0
Settings 1.0–6000.0 mm
 The initial reel diameter means the reel diameter at the startup. For the rewind zone, it’s the
diameter of the reel axle; for the unwind zone, it’s the diameter of the reel.
 When Pr.12-30 = 1, this parameter is read only.
