Delta MH300 Series

Chapter 12 Description of Parameter Settings
MH300
12.1-12-13
12-32
Initial Reel Diameter 1
Default: 1.0
Settings 1.0–6000.0 mm
12-33
Initial Reel Diameter 2
Default: 1.0
Settings 1.0–6000.0 mm
 If user chooses more than one type of reel diameter, you can set Pr.12-30 as 0 (using RS-485
communication input).
For example: To plan HMI pages or use text panel (TP series of PLC products), you can change
the setting value of Pr.12-31 by using communication.
 When the drive is stop and in tension control mode,
 When the AC motor drive is at a standstill and in tension control mode, you can set three sections
of initial reel diameter (Pr.12-31–Pr.12-33) by using multi-function terminal 87 and 88.
After finishing the setting of MI =87 and MI = 88, executes the function of MI = 86. See the table
below:
MIx = 88
MIx = 87
MIx = 86
OFF
OFF
ON: the setting value of Pr.12-31 will be wrote into Pr.12-40.
OFF
ON
ON: the setting value of Pr.12-32 will be wrote into Pr.12-40.
ON
OFF
ON: the setting value of Pr.12-33 will be wrote into Pr.12-40.
ON
ON
ON: the setting value of Pr.12-40 will be back to the default.
12-34
Pulses Per Revolution
Default: 1
Settings 1–60000 ppr
 When Pr.12-27 = 2 or 4, you have to set this parameter for setting the pulses per revolution of the
reel.
12-35
Revolutions Per Layer
Default: 1
Settings 1–10000
12-36
Material Thickness
Default: 0.001
Settings 0.001–65.000 mm
 Sets the thickness of the material to wind.

12-37
Reel Diameter Filter Time
Default: 1.00
Settings 0.00–100.00 sec.
 This parameter improves the instability of the reel diameter source (Pr.12-27).
