Chapter 12 Description of Parameter SettingsMH300
12.1-13-7
Setting 10: Logistics
The following table lists the relevant logistics setting application parameters.
Pr. Parameter Name Settings
00-20
Master frequency command source
(AUTO, REMOTE)
7 (Digital keypad potentiometer knob)
00-21
Operation command source
(AUTO, REMOTE)
1 (External terminals)
01-00 Motor 1 maximum operation frequency Default setting
01-01 Rated / base frequency of motor 1 Default setting
01-02 Rated / base voltage of motor 1 400.0
01-04 Mid-point voltage 1 of motor 1 20.0
01-06 Mid-point voltage 2 of motor 1 20.0
01-08 Minimum output voltage of motor 1 20.0
01-03 Mid-point frequency 1 of motor 1 1.50
01-07 Minimum output frequency of motor 1 1.50
01-12 Acceleration time 1 3 (sec.)
01-13 Deceleration time 1 3 (sec.)
01-24 S-curve for acceleration begin time 1 0.00
01-25 S-curve for acceleration arrival time 2 0.00
01-26 S-curve for deceleration begin time 1 0.00
01-27 S-curve for deceleration arrival time 2 0.00
06-03 Over-current stall prevention during acceleration 200
06-04 Over-current stall prevention during operation 200
06-05
Acceleration / deceleration time selection for
stall prevention at constant speed
2 (By the second acceleration /
deceleration time)
07-23 Automatic voltage regulation (AVR) function 1 (Disable AVR)
07-26 Torque compensation gain 0
Group setting 11: Tension PID function
The following table lists the tension PID function setting application related parameters.
Pr. Parameter Name Settings
00-20
Master frequency command source
(AUTO, REMOTE)
9 (PID function)
00-21 Operation command source (AUTO, REMOTE) 1 (External terminals)
01-00 Motor 1 maximum operation frequency Default setting
01-12 Acceleration time 1 3 (s)
01-13 Deceleration time 1 3 (s)
03-00 AVI analog input selection 5 (PID feedback signal)
03-50 Analog input curve selection 1 (Three-point curve of AVI)
03-63 AVI voltage lowest point 0.00
