Delta MH300 Series

Chapter 7 Optional AccessoriesMH300
7-30
Fig. 7-18
Unit: mm
Delta’s Part No. -
AC Input Reactor
A A1 B B1 B2 C C1 D D1*D2 E G1 G2 H
DR073AP334
228
240
215
40
170
133
75
8.5
7*13
152
176
200
97
DR091AP267
228
240
245
40
195
133
90
8.8
7*13
152
176
200
97
DR110AP221
228
240
245
40
195
138
95
8.5
7*13 152 176 200 102
Table 7-36
Torque: 58.2–64.3 kg-cm /
[50.5–55.8 lb-
in.] /
[5.7–6.3 Nm]
Terminals 4 mm
2
Torque:
8.2–10.2 kg-cm /
[7.1–8.9 lb-in.] /
[0.8–1.0 Nm]
