Delta MH300 Series

Chapter 7 Optional AccessoriesMH300
7-31
Fig. 7-19
Unit: mm
Delta’s Part No. -
AC Input Reactor
A A1 B B1 B2 C C1 D D1*D2 F G1 G2 H
M*T
DR150AP162
240
250
245
40
200
151
105
9
11*18
160
190
220
125
20*3
DR180AP135
240
250
245
40
200
151
105
9
11*18
160
190
220
125
20*3
Table 7-37
Terminals 4 mm
2
Torque:
8.2–10.2 kg-cm /
[7.1–8.9 lb-in.] /
[0.8–1.0 Nm]
PE Screw M8 x 23
Torque:
58.2–64.3 kg-cm /
[50.5–55.8 lb-in.] /
[5.7–6.3 Nm]
