102
BHT-1300B series
Setting the communication device
Select “3: DEVICE” to display the screen on the right.
The highlighted setting is the current setting.
 “2: COM2”: Setting the USB communication environments
1. Select “2: COM2” at the SET COMMUNICATION menu and then press
the ENT key.
The SET SERIAL PORT <COM2> menu screen on the right is displayed.
2. Use the cursor keys ([▲] [▼]) or numerical key ([1]) to highlight “1:
PROTOCOL”, and then press the ENT key.
Press and hold the BS/C key to return to the SET COMMUNICATION menu.
Setting the COM communication protocol options
Select “1: PROTOCOL” to display the screen on the right.
The highlighted setting is the current setting
“1: SERIAL No.”:
Selects whether or not to add serial numbers to the data blocks.
“2: H.PARITY”:
Selects whether or not to add a horizontal parity.
“3: LINKUP TIME”:
Selects the timeout length (in seconds) to be applied when a link is
established.
“4: FIELD SPACE”:
Specifies handling of the trailing spaces at the end of the field.
Select “Ignore” to trim the trailing spaces or “Data” to retain them as data.
To make changes, use the cursor keys ([▲] [▼]) or numerical keys ([1] [2] [3] [4]) to highlight the item to
be set, highlight the setting value using the cursor keys ([◄] [►]), and then press the ENT key.
Press and hold the BS/C key to return to the SET SERIAL PORT <COM2> menu.
- Point - Selecting the BHT-Ir or YMODEM protocol ignores the serial number and horizontal parity
settings.
SET SERIAL PORT
< COM2 >
1：PROTOCOL
SET PROTOCOL
< COM1 >
1：SERIAL No. ：ON OFF
2：H.PARITY ：ON OFF
3：LINKUP TIME ：
None 30 60 90 120
4：FIELD SPACE ：
Ignore Data
SET DEVICE
< COM1 >
1：DEVICE
Cradle IrDA
