Barcode Handy Terminal
USB Connection Test
1. Connect the BHT to the host computer via the USB cable.
2. Select “2: COM2” at the TEST menu and press the ENT key.
Then, Select “1: USB” at the TEST menu and press the ENT key.
The TEST COMMUNICATION screen on the right is displayed during the
test on the USB connection.
Press and hold the BS/C key to abort the test and then return to the TEST
screen.
The buzzer sounds three times if the communication does not complete
even if 15 seconds have elapsed.
Press and hold the BS/C key to return to the TEST screen.
Upon normal completion of the test, the buzzer sounds once and the
screen on the right is displayed.
Press and hold the BS/C key to return to the TEST screen.
TEST COMMUNICATION
< U S B >
* * C o n n e c t I n g * *
TEST COMMUNICATION
< U S B >
* * C o n n e c t I n g N G *
*
TEST COMMUNICATION
< U S B >
* * C o n n e c t I n g O K *
*
