Denso BHT-1306BWB - Cradle (CU) Connection Test

138
BHT-1300B series
Cradle (CU) Connection Test
1. Connect the CU-1321 to the host computer and set the BHT on the CU-1321.
2. Select “1: COM1” at the TEST menu and press the ENT key.
Then, Select “2: Cradle” at the TEST menu and press the ENT
key.
The TEST COMMUNICATION screen on the right is displayed during the
test on the Cradle connection.
Press and hold the BS/C key to abort the test and then return to the TEST
screen.
The buzzer sounds three times if the communication does not complete
even if 15 seconds have elapsed.
Press and hold the BS/C key to return to the TEST screen.
Upon normal completion of the test, the buzzer sounds once and the
screen on the right is displayed.
Press and hold the BS/C key to return to the TEST screen.
TEST COMMUNICATION
< C r a d l e >
* * C o n n e c t I n g * *
TEST COMMUNICATION
< C r a d l e >
* * C o n n e c t I n g N G * *
TEST COMMUNICATION
< C r a d l e >
* * C o n n e c t I n g O K * *
