BHT-1300B Series
2.6 Turning OFF the Power
Use one of the following three methods to turn OFF the BHT power.
Methods Operation Data Backup Timing
1) Normal power OFF Press the Power key. After 20 minutes from turning off
2) Turning the power
OFF after data backup
Hold down the Power key for at least 3
seconds.
When the power turns off
3) Auto power OFF The power turns OFF itself when the BHT is
not used for the specified period of time set.
After 20 minutes from turning off
2.6.1 Normal Power OFF
1. Press the Power key ( ).
The BHT power turns OFF after the screen on the right is displayed.
 Point  Do not remove the battery cartridge while the
message on the right is displayed.
When the power is next turned ON, there are times
when a message (2XXX ) appears asking the use
r
to contact the administrator.
2.6.2 Turning the Power OFF after Data Back-up
1. Hold down the Power key ( ) for at least 3 seconds.
The message right is displayed and data back-up is commenced.
The power turns OFF automatically when the back-up is complete.
 Point  Do not remove the battery cartridge while the
message on the right is displayed.
The back-up process may take several tens o
f
seconds depending on the amount of data.
2.6.3 Auto Power OFF
The power turns OFF automatically when the BHT is not used for the length of time set at the user
program.
The default time is set to 3 minutes when the BHT is shipped from the factory.
* Refer to “BHT-1300 Programmer’s Manual” for details of auto power OFF.
