1.1 System Configuration
This section describes the hardware and software required for the code data collection system using the BHT.
1.1.1 Hardware Configuration
In addition to the BHT, the following hardware and software are required for the code data collection
system using the BHT.
Please note that certain components of the required hardware will differ depending on the type of
communication used.
 Host computer
 CU-1300 Series (option): Optical communication unit
 Connection cable (option): Used to connect the CU and host computer.
 Wireless LAN access point (option)
 Bluetooth
® compatible device (option)
● Devices required for system configuration
Host
computer
BHT CU
Wireless LAN
access point
Bluetooth® / /Irda
compatible device
Ref. Page
(1) Infrared communication
–  – –

Page 37
(2) USB communication
  – –
–
Page 38
(3) Wireless LAN
communication
  – 
–
Page 39
(4) Bluetooth
®
wireless
communication
 * 
– –

Page 40
(5) Cradle communication
 

–
–
Page 38
* When the host computer is equipped with the Bluetooth
®
wireless communication device.
Wireless LAN
access point
(Option)
CU (Option)
(5) Cradle
communication
BHT
(3) WirelessLAN
communication
Connection cable
(Option)
Host computer
(Option)
(2) USB communication
(1) Infrared communication
(4) Bluetooth
®
wireless
communication
(4) Bluetooth
®
wireless
conmunication
Bluetooth
®
printer (Option)
IrDA printer (Option)
