BHT-1300B Series
8.1.4 Interface Specifications
IrDA Interface
Specification: IrDA Ver1.2 Low Power physical layer compliant
(Except transmission speed: 460800 bps)
Input signals: RD
Output signals: SD
Transmission speed: 9600 / 19200 / 38400 / 57600 / 115200 / 460800
Note: 460800 bps applies only to the communication between the BHT-1300s and that between the BHT
and the CU-1311 or CU-1321.
The maximum transmission speed in all other cases is 115200 bps.
Wireless Interface (BHT-1306BWB)
IEEE802.11b/g/n
Frequency band: 2412 – 2472 MHz
Communication method
and Transmission speed:
OFDM (65/58.5/52/39/26/19.5/12/6.5) Mbps
(54/48/36/24/18/12/9/6) Mbps
DSSS (11/5.5/2/1) Mbps
Channels: 11b/g/n: 1 – 13 (14 ch. not supported)
Bluetooth
®
Interface (BHT-1306BWB / BHT-1306BB)
Compatible specification: Bluetooth
®
Specification Ver. 2.1+EDR
Output class: Class 2 (Max. 2.5 mW)
Compliant profile: Generic Access Profile
Serial Port Profile
Dialup Networking Profile
USB Interface
Compatible specification: USB1.1
Connector: micro-USB
Device current consumption: Max. 500 mA
