241
Barcode Handy Terminal
*1 Under the following conditions:
- Ambient brightness: 500 lx. (Xenon arc lamp)
- Code 39, 19-digits
Narrow bar: Wide bar = 1 : 2.2
- Reflection intensity of white bars: min. 85 %
Reflection intensity of black bars: max. 5 %
PCS value 0.9 min
*2 Under the following conditions:
- Ambient brightness: 500 lx. (Xenon arc lamp)
- Code 39, 15-digits
Narrow bar: Wide bar = 1 : 2.2
- Reflection intensity of white bars: min. 85 %
Reflection intensity of black bars: max. 5 %
PCS value 0.9 min.
*3
Under the following conditions:
- Ambient brightness: 500 lx. (Xenon arc lamp)
- EAN-13
- Reflection intensity of white bars: min. 85 %
- Reflection intensity of black bars: max. 5 %
- 1.0 magnification PCS value 0.9 min.
*4 Under the following conditions:
- Ambient brightness: 500 lx. (Xenon arc lamp)
- Logistics ITF conforming to the UPS shipping
Container Code
- Reflection intensity of white bars: min. 85 %
- Reflection intensity of black bars: max. 5 %
- 0.5 magnification
*5
Under the following conditions:
- Ambient brightness: 500 lx. (fluorescent lamp)
- Logistics ITF conforming to the UPS shipping
Container Code
- Reflection intensity of white bars: min. 85 %
- Reflection intensity of black bars: max. 5 %
- 1.0 magnification
