Denso BHT-1306BWB - Code Specifications; Universal Product Codes; Required Optical Properties

239
Barcode Handy Terminal
8.1.2 Code Specifications
:
Barcode Type Bar Dimensions Scan Magnification
Universal product codes
JAN-13 (EAN-13)
JAN-8 (EAN-8)
UPC-A
UPC-E
JAN-13 (EAN-13) with add-on
JAN-8 (EAN-8) with add-on
UPC-A with add-on
UPC-E with add-on
2-dgit add-on
5-dgit add-on
Min. 0.26 mm
Min. 0.8
Interleaved 2of5 (ITF)
Standard 2of5 (STF)
Codabar (NW-7)
Code 39
Min. 0.125 mm
PCS value  0.9
Black/white bar reflection intensity difference  0.8
Min. 0.15 mm
(PCS value  0.45)
Code 93
Code 128, GS1-128 (EAN-128, UPC-128)
Min. 0.15 mm
PCS value  0.9
Black/white bar reflection intensity difference  0.8
Min. 0.19 mm
(PCS value  0.45)
GS1 DataBar
TM
(RSS)
GS1 DataBar Omnidirectional
GS1 DataBar Truncated
GS1 DataBar Stacked
GS1 DataBar Stacked Omnidirectional
GS1 DataBar Limited
GS1 DataBar Expanded
GS1 DataBar Expanded Stacked
Min. 0.15 mm
(PCS value  0.9)
Black/white bar reflection intensity difference  0.8
Required Optical Properties
White bars: Reflection intensity of 45% or higher
Black bars: Reflection intensity of 25% or lower
PCS value of 0.45 or higher
The reflection intensity is regulated with a light source with spectral peak of 633 nm and spectrum range of
610 to 650 nm.
