BHT-1300B Series
6.1 Replacing the Battery Cartridge
6.1.1 Battery Cartridge Service Life
The battery cartridge is a consumable part and should be replaced after being charged approximately 300
times.
The performance of the battery cartridge’s lithium-ion battery will deteriorate gradually with repeated
charging, even during normal use. When the battery operation time becomes shorter even after charging
for the specified length of time, replace the battery with a new one.
6.1.2 Battery Cartridge Replacement Method
1. Press the power key ( ) to turn OFF the BHT power.
The screen on the right displays.
 Point  Do not remove the battery cartridge until the
power turns OFF and the screen display
clears.
2. Slide the battery cartridge cover release
button (1) in the direction indicated by the
arrow and remove the battery cartridge
cover (2), and then remove the battery
cartridge (3).
3. Check the battery cartridge terminals on the new
battery cartridge and then insert in the direction shown
by the arrow.
(Refer to Chapter “2 BHT Preparation” – 2.2 “Loading and
Charging the Battery Cartridge”.)
 Point  Do not use battery cartridges other than that
specified by DENSO WAVE.
Terminals
