Barcode Handy Terminal
*1: The codes with more than 4 digits are read for ITF.
*2: CODE MARK Type 2 is the Code Mark system that is compliant with “Guidelines on Symbology
Identifiers” by AIM USA . Suffix “m” differs from the data format of bar code system, as shown in the table
below.
e.g.) ]I1 ]: Flag Character (ASCII 93)
I: Code Character (ITF)
1: Modifer Character (tabel below)
For example, ITF is set to read “with C/D, code mark is “]I1”
Code type
Modifer
Character
Comment
0 Read without C/D Standerd 2 of 5 (STF)
1 Read with C/D
0 Read without C/D Interleaved 2of5 (ITF)
1 Read with C/D
0 Read without C/D Code 39
1 Read with C/D
0 Read without C/D Codabar (NW7)
1 Read with C/D
0
The 1
st
and 2
nd
characters from the start code doesnt include
FNC1.
Code 128
2 The 2
nd
character from the start code is FNC1
C/D: check digits
*3: The code types that are not compliant with with “Guidelines on Symbology Identifiers” by AIM USA use
the Code mark Type 1.
