8.2.15.2 Longitudinal movement indicator and anti-tipping icon
The tipping indicator is displayed by a bar "1" (fig. 1509311),
whichindicatesthevehicleriskoftipping.
When the vehicle is about to reach the tipping,the Tipping
hazard icon "2" starts flashing. It will stop flashing when the
vehiclereturnswithinthesafetyparameters.
Thedegreeofstabilityofthevehicleisindicatedby:
– Tippingstatusbar"1"
– Signalingicon"2"
– Acousticsignaling
Thesignalingincreasesproportionatelywhilethevehicletipping
riskincreasesloadhandlingoperations,asdescribedinthetable
below.
Whenthelimitloadisreached,thedevicestopsthemovements
ofthevehicleconsideredaggravating,thealarmstopswhenthe
safetyconditionsarerestored.
1
2
150931-1
Load
Icon
Status
bar
Status Condition Acoustic
signaling
Load 90% less than the
maximumallowedload
Within
the
green
zone
Steadyon Workinsafeconditions None
Load 90% greater than the
maximumpermittedload
Yellow
zone
start
Flashing Prealarmcondition Intermittent
Load at 100% of maximum
allowedload
Red
zone
start
Steadyon Vehicleatthetipping
limit
Continuous
Load 100% greater than the
maximumpermittedload
Red
zone
end
Aggravating
movementslock
Continuous
