Components description | 8

DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A 147

Winchmethodofuse:SingleTow

Winchmethodofuse:DoubleTow

Jibwithhook(Dimensions)

Latticeextension(Dimensions)

"Gooseneck"jib(Dimensions)

Hookforforkcarrierplate

Gripperforpipewithpipelocker

Cylindersmanipulatinggripper

Wheelsmanipulatinggripper

Sheetsholdinggripper

5teethpolypgrabgripper

Centeringlayer

Negativejib
