8 | Components description

148 DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A

Positivejib

FixedFrontbasket

ExtensibleFrontbasket

FixedTrilateralbasket

ExtensibleTrilateralbasket

Trilateralbasket(X°=RightrotationY°=Leftrotation)

8.18.1.4 Operating modes legend for capacity diagrams

Maximumpressureappliedontheground

Prohibitionofoperatingwithunleveledmachine

Stabilizerslowered,0%extended

Stabilizerslowered,50%extended

Stabilizerslowered,100%extended

Prohibitedtoworkontires

Stabilizerslifted
