8 | Components description
80 DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A
Whenthelowbeamlightsareactivatedtheinstrumentpanelofthemachinelightson.
NOTICE
It is possible to turn on the sidelights with the ignition key in "0" position, while it is necessary to bring the
ignition key in position "I" to turn on the low beam lights.
8.1.14.2 High beam lights
To turn on the high beam lights it is necessary to move the
multifunctionlever(fig.1504081).
– To make individual flashes with the high beam lights, pull
themultifunctionlevertowardthesteeringwheeltothefirst
click.Itispossibletousethisfunctionwiththelightsoffand
theignitionkeyinposition"0".
– Toturnonthehighbeamlights,pullthemultifunctionlever
towardthesteeringwheeltothesecondclick.Itispossible
toturnonthehighbeamlightsonlywiththeignitionkeyin
position "I" and low beam lights on. The high beam lights
turned on is indicated by the warning light "1" on the
instrumentpanel.
Inbothcases,onceobtainedthedesiredclick,themultifunction
leverreturnstoitsrestposition.
1
150408-1
8.1.14.3 Cab front light *
NOTICE
* The cab front light is an optional accessory.
Press the switch "1" (fig. 1504091) located on the canopy
instrumentpaneltoturnonthefrontworklight.
Thewarninglightonthesameswitchindicatesthatthelightis
turnedon.
1
150409-1
NOTICE
To turn on the headlight it is necessary to bring the ignition key in position “I”.
8.1.14.4 Cab rear light *
NOTICE
* The cab rear light is an optional accessory.
