Duplo DC-616 Service Manual

140
Chapter 7 6 HELP Mode
S2-Y1540
HELP Mode : 16
1. Function
2. Operating Procedure
(1) Control panel check
• Check that the NUMERIC keys on the control panel work
correctly.
• Check that the buzzer of the keys on the control panel sounds
correctly.
• Check that the LEDs on the LED PCB function correctly.
(1) Control panel check
1. Access the HELP Mode “16”, and press the <START> key.
2. Press the NUMERIC keys. A buzzer sounds.
3. The LCD panel will be black while pressing the SET key.
The LED on the control panel and on the LED PCB blinks.
4. Press the <STOP> key. It will return to the HELP Mode selection
screen.
H16 Panel check
Key:Buzzer on
SET:LCD LED on
-0
