141
Chapter 7 6 HELP Mode
7
S2-Y1540
HELP Mode : 17
1. Function
2. Operating Procedure
(1) Paper feed elevator operation test
• The correct operation of the paper feed elevator is verifi ed.
• The status of the paper level sensor and the elevator lower
limit switch are verifi ed.
(1) Paper feed elevator operation test
1. Access the HELP Mode “17”, and press the <START> key.
2. Run the elevator by pressing the CURSOR (Up/Down) keys.
3. Press the CURSOR (Right/Left) keys to turn the pages.
4. The status of the sensor while the elevator is operating is verifi ed.
5. Press the <STOP> key. It will return to the HELP Mode selection
screen.
Sensor switch Elevator
upper limit
Elevator
lower limit
Level sen. 1: light blocked 0: light through
Low SW 0: OFF 1: ON
H17 Elevator ck.
Level sen. :
X
Low sw :
X
↑↓:Up,dw
-0
