142
Chapter 7 6 HELP Mode
S2-Y1540
HELP Mode : 18
1. Function
2. Operating Procedure
(1) Fan motor operation test
• The proper function of suction motor is veri ed.
• The proper function of blower motor is veri ed.
(1) Fan motor operation test
1. Access the HELP Mode “18”, and press the <START> key.
2. Press the UP/DOWN cursor key, and operate the fan motor.
• UP cursor key: Suction fan
• DOWN cursor key: Blower fan
3. Press the <STOP> key. It will return to the HELP Mode selection
screen.
H18 Air check
: Suction fan
:Blow out fan
-0
