180
Chapter 8 2 Service Person JOBs
S2-Y1540
Use to adjust the
vertical enlargement
magnifi cation) of
H-52. (using SRA3
exclusive paper)
This is used to check
the barcode reading
and to reset the
setting to the factory
preset state.(Can only
be used in the service
JOB Mode)
Use to check
performance.
Use to adjust the
gutter defl ector .
Use to check the
55 mm margin.
JOB Name H-52 CK2
BARCODE CK DEEP BLUE 6UP
GUTTER TEST MARGIN55 CK
Paper size
297×420(A3) 297×420(A3) 320×450
320×650
297×420
JOB number 91 93 94 95 96
PAPER WIDTH 297 297 320 320 297
TOTAL LENGTH 420 420 450 650 420
Side Mark 0 0 10 0 0
Lead Mark 0 0 10 0 0
SLIT1 0 0 10 10 55
SLIT2 0 0 300 300 285
SLIT3 0 0 100 100 0
SLIT4 0 0 210 210 0
SLIT5 0 0 110 110 0
SLIT6 0 0 200 200 0
CUT01 5 0 22 10 0
CUT02 405 0 225 325 0
CUT03 0 0 235 640 0
CUT04 0 0 438 0 0
CUT05 00000
CUT06 00000
CUT07 00000
CUT08 00000
CUT09 00000
CUT10 00000
CUT11 00000
CUT12 00000
CUT13 00000
CUT14 00000
CUT15 00000
CUT16-25 00000
CRE.01 0 0 147 0 0
CRE.02 0 0 360 0 0
CRE.03 00000
CRE.04 00000
CRE.05 00000
CRE.06 00000
CRE.07 00000
CRE.08 00000
CRE.09 00000
CRE.10 00000
CRE.
11-20
00000
PERF1
00000
PERF2
00000
AIR KNIFE OFF OFF OFF OFF OFF
SUCTION POWER
MAX MAX MAX MIN MAX
REG. MARK OFF OFF OFF OFF OFF
SLIT GUIDE
ON ON OFF OFF ON
AUTO CUT ON ON ON ON ON
CREASE DEPTH
MID MID MID MID MID
SPEED FAST FAST FAST SLOW FAST
-0
