Programming

Service Instructions 745-35-10 S/745-35-10 A - 02.0 - 04/2017 261

Test step by step

 The display switches to Test step by step.

Fig. 223: Test step by step

To carry out a step-by-step test:

1. Press the Test step by step

button.

2. Press the pedal after every single work step.

 The step by step test allows you to test the machine workflow.

3. To exit the test: access the menu again and press the OFF button.
