Edwards STP-iXA4507 Series User Manual

STP-iXA4507 series Turbomolecular Pump
MT-91E-001-0
Page 116
SERIAL COMMUNICATION PROTOCOL
PAG
E
116
5
5.4.21 ReadOptions
Function: Reading the setting value of the optional function; the parameter n depends on the optional
function.
Transmission frame:
PC->SIM
Stx
0
0
1
?
0
Parameter 1
Etx
LRC
SIM->PC
Ack
PC→SIM
Ack
SIM→PC
Stx
0
0
1
Sp
0
Parameter 1 to n
Etx
LRC
Parameter
Item
Data format
Remark
1
Optional function number
(receive/return)
16-bits hexadecimal
coded ASCII
see Table 31
2 to n
Function items (return)
Optional function number
Value
Total response parameter n
Remark
Second speed option setting
0014
4
see 5.4.21.1
Second speed selection
0015
2
see 5.4.21.2
TMS temperature
*1
001B
14
see 5.4.21.3
*1 Valid only with TMS specification
Table 31 - Option function number and parameter list
5.4.21.1 Second speed function setting
Settings for second speed can be changed.
Parameter
Item
Data format
Remark
1
Optional function number
16-bits hexadecimal
coded ASCII
0014
hex
2
Second speed setting
(Unit: Hz)
16-bits hexadecimal
coded ASCII
3
Second speed option
setting
16-bits hexadecimal
coded ASCII
0000
hex
：DISABLE
00FF
hex
：ENABLE
4
Selected speed value
(Unit: Hz)
16-bits hexadecimal
coded ASCII
